| Design |
Edge to edge glass |
| Diagonal |
17", 43cm |
| Panel |
TN |
| Native resolution |
1280 x 1024 (1.3 megapixel) |
| Aspect ratio |
5:04 |
| Panel brightness |
250 cd/m² |
| Brightness |
225 cd/m² with touch |
| Light transmittance |
90% |
| Static contrast |
1000:1 with touch |
| Response time (BTB) |
5ms |
| Viewing zone |
horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80° |
| Colour support |
16.7mln |
| Horizontal Sync |
31 - 80kHz |
| Viewable area W x H |
338 x 270.5mm, 13.3 x 10.6" |
| Pixel pitch |
0.264mm |
| Bezel colour and finish |
black, matte |
|
|
|
| Touch technology |
projective capacitive |
| Touch points |
10 (HID, only with supported OS) |
| Touch method |
stylus, finger, glove (latex) |
| Touch interface |
USB |
| Supported operating systems |
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
|
|
|
| Analog signal input |
VGA x1 |
| Digital signal input |
HDMI x1 |
| DisplayPort x1 |
| Audio input |
Mini jack x1 |
| Audio output |
Speakers 2 x 1W |
| HDCP |
yes |
|
|
|
| Water and dust protection |
IP54 (front) |
| OSD key lock |
yes |
|
|
|
| OSD languages |
EN, DE, FR, ES, IT, CN, JP |
| Control buttons |
Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power |
| User controls |
contrast, brightness, auto adjust, H.position, V.position, H.size, fine, OSD H.position, OSD V.position, OSD timeout, reset, input select, OSD language, colour temperature, volume, mute |
| Convenience |
Kensington-lock™ prepared |
| Plug&Play |
DDC2B |
|
|
|
| Tilt angle |
90° up; 5° down |
| VESA mounting |
100 x 100mm |
| Cable management system |
yes |
|
|
|
| Cables |
power, USB, HDMI, Audio, DP |
| Guides |
quick start guide, safety guide |
| Cable cover |
yes |
|
|
|
| Power supply unit |
internal |
| Power supply |
AC 100 - 240V, 50/60Hz |
| Power usage |
20W typical, 1.5W stand by, 0.3W off mode |
|
|
|
| Regulations |
CE, EAC, RoHS support, ErP, WEEE, cULus, VCCI, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) |
E |
| REACH SVHC |
above 0.1%: Lead |
|
|
|
| Product dimensions W x H x D |
387 x 378 x 240mm |
| Weight (without box) |
4.9kg |
| EAN code |
4,94857E+12 |
|
|
|
| Product series |
ProLite T1532MSC-B1S, ProLite T1732MSC-B1SAG, ProLite T1932MSC-W1SAG , ProLite T1932MSC-B1S |
