| DISPLAY CHARACTERISTICS |
|
| Diagonal |
19", 48cm |
| Panel |
TN |
| Native resolution |
1280 x 1024 @75Hz (1.3 megapixel) |
| Aspect ratio |
5:4 |
| Panel brightness |
250 cd/m² |
| Static contrast |
1000:1 |
| Advanced contrast |
12M:1 |
| Response time (GTG) |
3ms |
| Viewing zone |
horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80° |
| Colour support |
16.7mln (sRGB: 99%; NTSC: 72%) |
| Horizontal Sync |
30 - 80kHz |
| Viewable area W x H |
376.32 x 301.05mm, 14.8 x 11.9" |
| Pixel pitch |
0.294mm |
| Colour |
matte, white |
| |
|
| INTERFACES / CONNECTORS / CONTROLS |
|
| Signal input |
HDMI x1 (v.1.4)
DisplayPort x1 (v.1.2.) |
| HDCP |
yes |
| |
|
| FEATURES |
|
| OSD languages |
EN, DE, FR, ES, IT, PT, RU, JP, CZ, NL, PL |
| Control buttons |
Power, Menu, + / Volume, -/ Eco, Signal Select (Auto) |
| User controls |
picture adjust (contrast, brightness, i-Style colour, ACR, Eco, OD, X-Res technology), image setup (blue light reducer, sharpness), colour settings (gamma, 6-axis, colour temp.), audio settings (volume, mute), OSD settings (H. position, V. position, OSD time, OSD rotate, language), extra (reset, DDC/CI control, signal select, HDMI range, opening logo, power LED, information) |
| Speakers |
2 x 2W |
| Convenience |
Kensington-lock™ prepared, DDC2B, Mac OSX |
| |
|
| MECHANICAL |
|
| Display position adjustments |
height, swivel, tilt, pivot (rotation both sides) |
| Height adjustment |
150mm |
| Rotation (PIVOT function) |
90° |
| Swivel stand |
120°; 60° left; 60° right |
| Tilt angle |
23° up; 5° down |
| VESA mounting |
100 x 100mm |
| Cable management system |
yes |
| |
|
| ACCESSORIES INCLUDED |
|
| Cables |
power, HDMI |
| Other |
quick start guide, safety guide |
| |
|
| POWER MANAGEMENT |
|
| Power supply unit |
internal |
| Power supply |
AC 100 - 240V, 50/60Hz |
| Power usage |
12W typical, 0.5W stand by, 0.3W off mode |
| |
|
| SUSTAINABILITY |
|
| Regulations |
CE, TÜV-GS, RoHS support, ErP, WEEE, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) |
D |
| EPEAT |
*registration varies by country, go to www.epeat.net for details |
| REACH SVHC |
above 0.1%: Lead |
| |
|
| SUSTAINABILITY |
|
| Regulations |
CE, TÜV-GS, RoHS support, ErP, WEEE, REACH, UKCA |
| Energy efficiency class (Regulation (EU) 2017/1369) |
D |
| EPEAT |
*registration varies by country, go to www.epeat.net for details |
| REACH SVHC |
above 0.1%: Lead |
