TP-LINK GPON Terminal 8xXGS-PON (SFP+) + 2x10G SFP+ +2x40G QSFP+ + 1xLAN + 1xkonzol port, DS-P7500-08

Name: TP-LINK GPON Terminal 8xXGS-PON (SFP+) + 2x10G SFP+ +2x40G QSFP+ + 1xLAN + 1xkonzol port, DS-P7500-08
Brand: TP-LINK
SKU: CS_360149
Price: 3910970 HUF
Availability: InStock

Rendelhető

Cikkszám:

CS_360149

nettó: 3 079 504 Ft bruttó: 3 910 970 Ft

TP-LINK GPON Terminal 8xXGS-PON (SFP+) + 2x10G SFP+ +2x40G QSFP+ + 1xLAN + 1xkonzol port, DS-P7500-08

Adatok

Gyártó:

TP-LINK

Gyártói cikkszám:

DS-P7500-08

Garancia:

60 hónap

Gyártó::

TP-LINK

Rack-be szerelhető:

Van

Switch típus:

Modular

Menedzselhetőség:

Teljes

Portok száma:

Menedzselhető:

Van

PoE (Power over Ethernet):

Nincs

SFP port:

Gyártó:

TP-LINK

Garancia (hónap):

Termék gyártója:

TP-LINK

Részletek

HARDWARE FEATURES
Interface	8× XGS-PON & GPON Combo Ports (SFP+) 2× 40G QSFP+ Ports 2× 10G SFP+ Ports 1× RJ45 Management Port 1× RJ45 Console Port 1× Alarm Port
Button	Reset Button
Power Supply	Dual Power Supplies: 2 AC, 2 DC or AC+DC, AC: 100V~240V, 50/60Hz DC: -38.4V~-72V
Power Consumption	Max. 109.2W
Dimensions ( W x D x H )	17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm)

SOFTWARE FEATURES
Security	ACL 802.1x Authentication ARP Inspection IP Source Guard
DHCP	DHCP Server DHCP Relay
OMCI	Standard OMCI Management Supported
ONU Authentication	ONU Auto Authentication
ONU Security	Rouge ONU Detection and Isolation
Multi-Service	Multi-Service Traffic Identify and Rate Limit
QoS	IEEE 802.1p/DSCP QoS Voice VLAN Auto VoIP
Routing	Static Routing
Mulitcast	IGMP Snooping MLD Snooping
Centralized Management	Large-Scale Devices Management OLT Batch Configure, Upgrade, Reboot Multi-Site Management Intelligent Network Monitoring Real-time Network Overview

Combo PON Port Attribute
Max. Splitting Ratio	1:128 for GPON, 1:256 for XGS-PON
Transmission distance	20 km
Data rate	GPON Downstream: 2.5 Gbps, Upstream: 1.25 Gbps XGS-PON Downstream: 9.953 Gbps, Upstream: 9.953 Gbps
Wavelength	XGS-PON: Tx: 1577 nm Rx: 1270 nm GPON: Tx: 1490 nm Rx: 1310 nm

OTHERS
Certification	CE,FCC
Package Contents	Optical Line Terminal DS-P7500-8 AC Power Cord Console Cable Mouting Brackets, Screws and Rubber Feet Installation Guide
Environment	Operating Temperature: 0?–50? (32?–122?) Storage Temperature: -40?–70? (-40?–158?) Operating Humidity: 10%–90% non-condensing Storage Humidity: 5%–90% non-condensing

TP-LINK GPON Terminal 8xXGS-PON (SFP+) + 2x10G SFP+ +2x40G QSFP+ + 1xLAN + 1xkonzol port, DS-P7500-08

nettó: 3 079 504 Ft bruttó: 3 910 970 Ft
