Operating Ambient Temperature
0–40 °C
Dimensions
140 (L) x 140 (W) x 27 (H) mm
Net Weight
242 g
Fan Specifications
Fan Speed
400–2500 rpm, PWM controlled
0 rpm below 5 % PWM
Airflow
110 cfm | 186 m³/h
Static Pressure
5.2 mmH2O
Fan Bearing
Fluid Dynamic Bearing
Typical Voltage
12 V DC
Start Up Voltage
5 V DC
Current
0.35 A
Cable Length
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
