General Specifications
Operating Ambient Temperature
0–40 °C
Dimensions
120 (L) x 120 (W) x 25 (H) mm
Net Weight
185 g
Fan Specifications
Fan Speed
600–3000 rpm, PWM controlled
0 rpm below 5 % PWM
Airflow
77 cfm | 131 m³/h
Static Pressure
6.9 mmH2O
Fan Bearing
Fluid Dynamic Bearing
Typical Voltage
12 V DC
Start Up Voltage
3.3 V DC
Current
0.33 A
Cable Length
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
