General Specifications
TIM
MX-6 (0.8 g)
Warranty
6 Years
Operating Ambient Temperature
0—40 °C
Pump
800–2800 rpm
(PWM controlled)
Current | Voltage
0.35 A | 12 V DC
Cold Plate
Copper, Micro Skived Fins
Tube Length
450 mm
Tube Diameter
Outer: 12.4 mm
Inner: 6.0 mm
Weight
1905 g
Compatibillity
Intel
LGA1851, LGA1700
AMD
AM5, AM4
Radiator
Material
Aluminium
Dimensions
317 (L) x 138 (W) x 38 (H) mm
VRM Module
VRM Fan
400–2500 rpm
(PWM-controlled)
Current | Voltage
0.05 A | 12 V DC
Radiator Fan
General
2x P14 Pro
Speed
400–2500 rpm
Airflow
110 cfm | 186 m³/h3/h
Static Pressure
5.2 mmH2O
Bearing
Fluid Dynamic Bearing
Current | Voltage
0.35 A | 12 V DC
Connector
4-Pin Fan Plug
