ModelMPW-6001-ACBW-B
ATX VersionATX 12V Ver. 2.41
PFCActive PFC
Input Voltage200-240V
Input Current4.5A
Input Frequency50-60Hz
Dimensions (L x W x H)140 x 150 x 86 mm
Fan Size120mm
Fan BearingSleeve Fan
Efficiency≥ 85% @ Typical Load
ErP 2014 Lot 3Yes
Operating Temperature0-40°C
Power Good Signal100 - 500 ms
Hold Up Time≥10ms at 100% load
MTBF>100,000 Hours
ProtectionsOVP / OPP / SCP / UVP / OTP / Inrush Protection
RegulatoryTUV, cTUVus, CE, FCC, CCC, EAC, UKCA
ATX 24 Pin Connectors1
EPS 4+4 Pin Connectors1
SATA Connectors5
Peripheral 4 Pin Connectors3
PCI-e 6+2 Pin Connectors2
SeriesElite Series
Category500 to 750W
ModularNon Modular
80 Plus EfficiencyWhite
Form FactorATX
Watts600W
