| H190X |
|
| Big screen entertainment, bright HD ready projector |
| |
|
| |
|
| Specification |
|
| |
|
|
Display/image
|
|
| |
DLP™
|
| |
|
| |
Resolution
|
| |
WXGA (1280x800)
|
| |
|
| |
Brightness
|
| |
3,900 lumens
|
| |
|
| |
Contrast ratio
|
| |
30,000:1
|
| |
|
| |
Native aspect ratio
|
| |
16:10
|
| |
|
| |
Aspect ratio - compatible
|
| |
03:16,2
|
| |
|
| |
Keystone correction - vertical
|
| |
+/-40°
|
| |
|
| |
Horizontal scan rate
|
| |
15.38 ~ 91.15Khz
|
| |
|
| |
Vertical scan rate
|
| |
50 ~ 85(120 for 3D)Hz
|
| |
|
| |
Uniformity
|
| |
75%
|
| |
|
| |
Screen size
|
| |
0.82m ~ 7.61m (32.24" ~ 299.53") diagonal
|
| |
|
|
|
| |
|
|
Lamp info
|
|
| |
Lamp
|
| |
|
| |
Lamp watts
|
| |
203
|
| |
|
| |
Lamp life hours (up to)
|
| |
6000 (Bright), 12000 (Dynamic), 10000 (Eco), 15000 (Eco+)
|
| |
|
|
|
| |
|
|
Optical
|
|
| |
1.55:1 ~ 1.73:1
|
| |
|
| |
Projection distance (m)
|
| |
1m - 12m
|
| |
|
| |
Zoom
|
| |
1.1
|
| |
|
| |
Zoom type
|
| |
Manual
|
| |
|
| |
Focal length (mm)
|
| |
21.85 mm~24mm/0.86"~0.945"
|
| |
|
| |
Native offset
|
| |
112%
|
| |
|
|
|
| |
|
|
Connectivity
|
|
| |
Inputs 1 x HDMI 1.4a 3D support, 1 x VGA (YPbPr/RGB), 1 x Composite video, 1 x Audio 3.5mm
|
| |
Outputs 1 x VGA, 1 x Audio 3.5mm, 1 x USB-A power 1A |
| |
Control 1 x RS232 |
| |
|
|
|
| |
|
|
General
|
|
| |
27dB
|
| |
|
| |
Noise level (max)
|
| |
29dB
|
| |
|
| |
PC compatibility
|
| |
FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
|
| |
|
| |
2D compatibility
|
| |
NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz)
|
| |
|
| |
3D compatibility
|
| |
Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
|
| |
|
| |
3D
|
| |
Full 3D
|
| |
|
| |
Security
|
| |
Security bar, Kensington Lock, Password protected interface
|
| |
|
| |
OSD / display languages
|
| |
25 languages: Arabic, Czech, Danish, Dutch, English, Farsi, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Norwegian, Polish, Portuguese, Romanian, Russian, Chinese (simplified), Spanish, Swedish, Chinese (traditional), Turkish, Vietnamese
|
| |
|
| |
Operating conditions
|
| |
5°C~40°C/41°F~104°F, max altitude 3000M/9843ft, max humidity 85%
|
| |
|
| |
Remote control
|
| |
Card style
|
| |
|
| |
Speaker count
|
| |
1
|
| |
|
| |
Watts per speaker
|
| |
10W
|
| |
|
| |
In the box
|
| |
AC power cord
|
| |
Remote control |
| |
Battery |
| |
Basic user manual |
| |
|
| |
Optional wireless models
|
| |
WHD200
|
| |
|
|
|
| |
|
|
Power
|
|
| |
100 ~ 240V, 50 ~ 60Hz
|
| |
|
| |
Power consumption (standby)
|
| |
0.5W
|
| |
|
| |
Power consumption (min)
|
| |
187W
|
| |
|
| |
Power consumption (max)
|
| |
225W
|
| |
|
|
|
| |
|
|
Weight and dimensions
|
Dimensions (W x D x H) mm
|
| |
316 x 244 x 108
|
| |
|
| |
Gross weight
|
| |
3.58 kg
|
| |
|
| |
Net weight
|
| |
3.05 kg
|
