MERCUSYS 3G/4G Modem + Wireless Router N-es 300Mbps 1xWAN/LAN(100Mbps) +3xLAN(100Mpbs), MB115-4G

EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
CN:
FDD-LTE: B1/B3/B5/B8 (2100/1800/850/900 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)

N300

300 Mbps

IEEE 802.11b/g/n

2.4 GHz

11g 54M: -74.5 dBm
11n HT20 MCS7: -73.5 dBm
11n HT40 MCS7: -70.5 dBm

< 20 dBm (2.4 GHz)

WPA-PSK / WPA2-PSK

smart connect
WPS
Wireless Schedule
Wireless Clients Statistics

 219 × 140 × 32 mm

(8.62 × 5.51 × 1.26 in)

1× 10/100Mbps LAN/WAN Port

3× 10/100Mbps LAN Ports

1× Nano SIM Card Slot

2× External 4G LTE Antennas,
2× External Wi-Fi Antennas

WPS?Reset Button

9V/0.85A

1× Power
1× Internet
1× LAN
3× Signal

Cat 4
150/50Mbps DL/UL

3G/4G Router
Wireless Router

4G Preferred
4G Only
3G Only

Data Roaming
Network Search
Profile Create
APN Settings
ISP File Upgrade
PIN Management

Dynamic IP
Static IP
PPPoE
PPTP
L2TP

ALG
Virtual Server
Port Triggering
UPnP
DMZ

IPv4, IPv6

Data Statistics
Data Limit

Time Control
Website Filtering

2.4 GHz Guest Network

Server
DHCP Client List
Address Reservation

MERCUSYS DDNS
DynDns
NO-IP

Inbox
New Message
Outbox
Drafts

IPv4 SPI Firewall
Access Control
Service Filtering
IP & MAC Binding
IPv6 Firewall

Time Settings
LED Control
Diagnostics
Firmware Upgrade
Backup&Restore
Reboot
Administration
System Log
CWMP Settings

MERCUSYS APP
Web GUI

English
Spanish
Italian
Polish
Russian

√

300 Mbps Wireless N 4G LTE Router (MB115-4G)

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~60°C (-40°F~140°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing
