MERCUSYS 3G/4G Modem + Wireless Router AC1200 1xWAN/LAN(1000Mbps) +3xLAN(1000Mpbs), MB235-4G

MERCUSYS 3G/4G Modem + Wireless Router AC1200 1xWAN/LAN(1000Mbps) +3xLAN(1000Mpbs), MB235-4G

Name: MERCUSYS 3G/4G Modem + Wireless Router AC1200 1xWAN/LAN(1000Mbps) +3xLAN(1000Mpbs), MB235-4G
Brand: TP-LINK
SKU: CS_382186
Price: 31330 HUF
Availability: InStock

Központi készleten, szállítás 2-3 nap!

Cikkszám:

CS_382186

Megtakarítás: 15 650 Ft

RRP: nettó: 36 992 Ft bruttó: 46 980 Ft

nettó: 24 669 Ft bruttó: 31 330 Ft

Raktárkészletek

Központi készleten 17 db

MERCUSYS 3G/4G Modem + Wireless Router AC1200 1xWAN/LAN(1000Mbps) +3xLAN(1000Mpbs), MB235-4G

Adatok

Gyártó:

TP-LINK

Gyártói cikkszám:

MB235-4G

EAN:

6957939004088

EAN:

6957939004088

Szabvány:

802.11b, 802.11g, 802.11n, 802.11ac

Garancia:

36 hónap

Gyártó::

TP-LINK

Frekvencia:

2.4 GHz és 5 GHz

Wifi sebesség:

1200 Mbit/s

SIM:

Van

LAN portok:

Mesh router:

Van

WAN sebesség:

10/100/1000 Mbit/s

LAN sebesség:

10/100/1000 Mbit/s

Gyártó:

TP-LINK

Garancia (hónap):

Termék gyártója:

TP-LINK

Tömeg:

840 g/db

Részletek

Network Type

EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)

Wi-Fi Class

AC1200

Wi-Fi (2.4 GHz)

300 Mbps

Wi-Fi ( 5 GHz)

867 Mbps

Wireless Standards (Invaild)

IEEE 802.11ac/a/b/g/n

Frequency

5 GHz, 2.4 GHz

Reception Sensitivity

11g 6Mbps: -95dBm

11g 54Mbps: -77dBm

11n HT20 MCS7: -74dBm

11n HT40 MCS7: -71dBm

11a 6Mbps: -92dBm

11a 54Mbps: -75dBm

11ac VHT20 MCS8: -70dBm

11ac VHT40 MCS9: -65dBm

11ac VHT80 MCS9: -61dBm

Transmission Power

2.4 GHz < 20dBm (EIRP)

5 GHz < 23dBm (EIRP)

Wireless Security

WPA-PSK / WPA2-PSK / WPA3-SAE

Wireless Functions

smart connect
WPS
Wireless Schedule

Others

Package Contents

4G+ Cat6 AC1200 Wireless Dual Band Gigabit Router (MB235-4G)

Power Adapter

RJ45 Ethernet Cable

Quick Installation Guide

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~60°C (-40°F~140°F)

Operating Humidity: 10%~90% Non-Condensing

Storage Humidity: 5%~90% Non-Condensing

Software

Operation Mode

3G/4G Router
Wireless Router

Cellular Mode

4G Mode
3G Mode

Cellular APN

Data Roaming
Band Search
Network Search
Profile Create
APN Settings
ISP File Upgrade
PIN Management

WAN Mode

Dynamic IP
Static IP
PPPoE
PPTP
L2TP

NAT Forwarding

ALG
Virtual Server
Port Triggering
UPnP
DMZ

Protocols

IPv4, IPv6

Data Settings

Data Statistics
Data Limit

Parental Controls

Time Control
Website Filtering

Guest Network

2.4 GHz Guest Network
5 GHz Guest Network

DHCP

Server
DHCP Client List
Address Reservation

DDNS

MERCUSYS DDNS
DynDns
NO-IP

SMS

Inbox
New Message
Outbox
Drafts

QoS

√

Security

IPv4 SPI Firewall
Access Control
IP & MAC Binding
IPv6 Firewall

System Settings

Time & Language
LED Control
Diagnostics
Firmware Upgrade
Backup&Restore
Reboot
Administration
System Log
CWMP Settings

Device Management

MERCUSYS APP
Web GUI

System Language

English
Deutsch
Espanol
Français
Italiano
Polski
???????

TR-069

√

Hardware

Dimensions

209 × 171.9 × 41.7 mm
(8.2 × 6.8 × 1.6 in)

Interfaces

1× Gigabit LAN/WAN Port
3× Gigabit LAN Ports
1× Nano SIM Card Slot

Antenna

2× External Detachable 4G LTE Antennas,
2× External Wi-Fi Antennas

Button

WPS, Reset Button

External Power Supply

12V/1A

LED

1× Power
1× Internet
1× LAN
3× Signal

LTE Standard

Cat 6
300/50Mbps DL/UL

Wireless
