| PERFORMANCE |
| Processor |
Intel® Core™ Ultra 5 228V, 8C (4P + 4LPE) / 8T, Max Turbo up to 4.5GHz, 8MB |
| AI PC Category |
Copilot+ PC |
| NPU |
Integrated Intel® AI Boost, up to 40 TOPS |
| Graphics |
Integrated Intel® Arc™ Graphics 130V |
| Chipset |
Intel® SoC Platform |
| Memory |
32GB Soldered LPDDR5x-8533, MoP Memory |
| Memory Slots |
Memory soldered to systemboard, no slots, dual-channel |
| Max Memory |
32GB soldered memory, not upgradable |
| Storage |
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0 |
| Storage Support |
One drive, up to 2TB M.2 2242 SSD |
| Storage Slot |
One M.2 2242 PCIe® 4.0 x4 slot |
| Card Reader |
None |
| Audio Chip |
High Definition (HD) Audio, Cirrus Logic® CS42L43 |
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos® |
| Camera |
FHD 1080p + IR Discrete with E-shutter |
| Microphone |
2x, Array |
| Battery |
Integrated 55Wh |
| Power Adapter |
65W USB-C® Slim GaN (3-pin) |
| DESIGN |
| Display |
14" WUXGA (1920x1200) OLED 400nits Anti-glare, 100% DCI-P3, 60Hz, DisplayHDR™ True Black 500, Dolby Vision® |
| Touchscreen |
None |
| Keyboard |
Backlit, Hungarian |
| Touchpad |
Buttonless glass surface multi-touch Haptic Touchpad, supports Precision TouchPad (PTP), 80 x 130 mm (3.15 x 5.12 inches) |
| Case Color |
Grey |
| Case Material |
Aluminium (Top), Aluminium (Bottom) |
| Pen |
Pen Not Supported |
| Dimensions (WxDxH) |
311.8 x 212.3 x 6.7 - 17.18 mm (12.28 x 8.36 x 0.26 - 0.68 inches) |
| Weight |
Starting at 1.21 kg (2.66 lbs) |
| SOFTWARE |
| Operating System |
Windows® 11 Pro, Hungarian / English |
| Bundled Software |
Intel® Connectivity Performance Suite |
| CONNECTIVITY |
| Ethernet |
No Onboard Ethernet |
| WLAN + Bluetooth |
Intel® Wi-Fi® 7 BE201, 802.11be 2x2 + BT5.4 |
| WWAN |
Non-WWAN |
| SIM Card |
None |
| NFC |
None |
| Standard Ports |
- 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1
- 1x HDMI® 2.1, up to 4K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
|
| Optional Ports (configured) |
None |
| Docking |
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® X9-14 Gen 1 |
| SECURITY & PRIVACY |
| Smart Card Reader |
None |
| Security Chip |
Discrete TPM 2.0 Enabled |
| Fingerprint Reader |
Touch Style, Match-on-Chip, Integrated in Power Button |
| Other Security |
- E-shutter
- IR camera for Windows® Hello (facial recognition)
- Ultrasonic Human Presence Detection (WUXGA models)
|
| MANAGEABILITY |
| System Management |
Non-vPro® |
| SERVICE |
| Base Warranty |
3-year, Courier or Carry-in |
| Included Upgrade |
3Y Premier Support Upgrade from 3Y Courier/Carry-in |
| ACCESSORIES |
| Bundled Accessories |
None |
| CERTIFICATIONS |
| Green Certifications |
- ENERGY STAR® 8.0
- EPEAT™ Gold Registered
- ErP Lot 6/26
- RoHS compliant
- TCO Certified 10.0
|
| Other Certifications |
- Intel® Evo™ Platform
- Eyesafe® Certified 2.0
|
| Mil-Spec Test |
MIL-STD-810H military test passed |
