HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960

HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960

Name: HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960
Brand: HP NW
SKU: CS_383372
Price: 486520 HUF
Availability: InStock

Rendelhető

Cikkszám:

CS_383372

nettó: 383 087 Ft bruttó: 486 520 Ft

HPE Networking Instant On Switch 8p Gigabit CL4 4p SR2.5G CL6 PoE 2p 10GBT 2p SFP+ 480W 1960

Adatok

Gyártó:

HP NW

Gyártói cikkszám:

S0F35A

Garancia:

1188 hónap

Gyártó::

HP HEWLETT PACKARD

Gyártó:

HP HEWLETT PACKARD

Garancia (hónap):

1188

Termék gyártója:

HP NW

Részletek

Product	1960 8p CL4 4p SR CL6
Part Number	S0F35A
Switch Type	Fixed Port
Network OS	Aruba Instant On
Routing / Switching	Layer 2 Only
Management	Smart Managed
Included Accessories
Included Accessories	N/A
Physical Properties
Dimensions	17.44(w) x 13.78(d) x 1.73(h) in (44.3 x 35 x 4.4 cm) (1U height)
Weight	11.55lb (5.24kg)
Port Types
LAN Ports	8 RJ-45 autosensing 10/100/1000BASE-T ports with IEEE 802.af/at CL4 PoE
Dual Personality Ports	N/A
1/2.5/5/10GbE	4 RJ-45 autosensing 1G/2.5GBASE-T ports with IEEE 802.af/at/bt CL6 PoE
SFP Ports	N/A
SFP+ Ports	2 SFP+ 10GbE ports
SFP28 Ports	N/A
SFP56 Ports	N/A
XFP Ports	N/A
X2 Ports	N/A
CX4 Ports	N/A
10GBASE-T Ports	2 RJ-45 autosensing 100/1000/10GBASE-T ports
QSFP+ Ports	N/A
QSFP28 Ports	N/A
QSFP56 Ports	N/A
QSFP-DD Ports	N/A
Module Slots	N/A
Console Port	N/A
Power Supplies
Power supply slots	Internal power supply
Power supply requirements	N/A
Memory and Processor
Memory and Processor	ingle-Core ARM v7 Cortex-A9 @800MHz 1GB DDR3; 512MB NAND flash; Packet buffer size: 1.5 MB
Gigabit Module	N/A
10Gb Module	N/A
Management Module	N/A
Fabric Module	N/A
I/O Module	N/A
Mounting
Mounting	Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)
Performance
100 Mb Latency	< 4.1 µs
1000 Mb Latency	< 1.8 µs
10 Gbps Latency	< 2.8 µs
40 Gbps Latency	N/A
Throughput	172 Mpps
Switching Capacity	116 Gbps
Switch Fabric Speed	N/A
Routing Table Size	992
MAC Address Table Size	16000 entries
MACsec Capable Hardware	N/A
MACsec Software Support	N/A
MACsec with EAP-TLS	N/A
MACsec Capable Uplink Ports	N/A
Electrical Characteristics
Description	N/A
Voltage	100-127VAC / 200-240VAC
Current	6.4A/3.0A
Frequency	50/60 Hz
Maximum Power Consumption	100-127V: 635W 200-220V: 623W
Maximum Heat Dissipation	N/A
PoE power	480
Notes	Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.
Management
Management	IMC - Intelligent Management Center, Web browser, SNMP Manager, IEEE 802.3 Ethernet MIB
