| Product |
AP-505H |
| Part Number |
R3V54A
R3V52A
R3V50A
R3V46A
R3V48A
R3V55A
R3V53A
R3V51A
R3V47A
R3V49A |
| Description |
Indoor, dual radio, 5GHz 802.11ax 2x2 MIMO and 2.4GHz 802.11ax 2x2 MIMO |
| Product Type |
Access Point |
| Ports |
1x 100/1000/2500BASE-T, 4x 10/100/1000 |
| Number of Radios |
2 |
| Wi-Fi Alliance Certification |
•Wi-Fi CERTIFIED a, b, g, n, ac
•Wi-Fi CERTIFIED 6 (ax)
•WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open ( OWE)
•WMM, WMM-PS, Wi-Fi Vantage, Wi-Fi Agile Multiband
•Passpoint (release 2)
•Bluetooth SIG
•Ethernet |
| Performance |
|
| Memory and Processor |
N/A |
| MAC Address Table Size |
N/A |
| Electrical Characteristics |
|
| Maximum Heat Dissipation |
N/A |
| Maximum Power Rating |
DC: 13.0W (19.0W, 44.0W, 50.0W)
802.3bt: 14.0W (20.0W, 45.0W, 51.0W)
802.3at (IPM enabled): 14.0W (20.0W, 25.5W, 25.5W)
802.3af (IPM enabled): 13.5W (13.5W, 13.5W, 13.5W) |
| Power Inputs |
DC: 13.0W (19.0W, 44.0W, 50.0W)
802.3bt: 14.0W (20.0W, 45.0W, 51.0W)
802.3at (IPM enabled): 14.0W (20.0W, 25.5W, 25.5W)
802.3af (IPM enabled): 13.5W (13.5W, 13.5W, 13.5W) |
| Antenna Connector |
N/A |
| Antenna |
Two integrated semi-directional antennas for 2x2 MIMO with peak antenna gain of 6.3dBi in 2.4GHz and 4dBi in 5GHz. Built-in antennas are optimized for vertical wall or desk mounted orientation of the AP. |
| Number of Internal Antennas |
Two integrated semi-directional antennas for 2x2 MIMO with peak antenna gain of 6.3dBi in 2.4GHz and 4dBi in 5GHz. |
| Number of External Antennas |
N/A |
| Notes |
N/A |
| Physical Characteristics |
|
| Dimensions |
86mm (W) x 50mm (D) x 150mm (H) |
| Weight |
360g |
| Additional Details |
|
| MIMO |
2x2 |
| Spatial Streams |
2
5GHz radio: Two spatial stream (SU) MIMO for up to 1.2Gbps wireless data rate (HE80)
2GHz radio: Two spatial stream (SU) MIMO for up to 287Mbps wireless data rate (HE20) Note: HE40 operation is supported in 2.4GHz, but uncommon and not recommended |
| Notes |
N/A |
