| Item |
CS6580-32CQ-HI |
CS6580-48S6Q-HI |
|
Port Fisik |
32 x 100G QSFP28 |
48 x 25G/10G (SFP28) + 6x 100G QSFP28 |
|
Port manajemen |
Port Konsol RJ45
Port manajemen ethernet RJ45 100/1000Mbps
Port Manajemen USB2.0 |
|
Performa |
|
Kapasitas Switching |
6.4Tbps |
3.6Tbps |
| Troughput |
4.7Bpps |
2.6Bpps |
|
Alamat MAC |
8K min./104K max. |
|
Tabel ARP |
8K min./32K max. |
|
Tabel Routing |
8K min./128K max. |
|
Physical |
|
Dimensi(W*H*D) |
438mm*44mm*515mm |
438mm*44mm*515mm |
| Kelembaban relatif |
5%~95% non-condensing |
| Suhu |
Working 0°C~45°C, storage -40°C~70°C |
|
Input Daya |
AC: 100~240V,50~60 Hz |
| Sumber daya listrik |
1+1 Modular Redundant AC |
| Konsumsi daya |
< 511w |
< 550w |
| Fitur Utama |
|
Fitur L1, L2 |
Frame Jumbo 9k
Port Loopback Detect
LLDP and LLDP-MED
UDLD
802.3ad LACP, 16 groups
LACP Load Balance |
|
N:1 Port Mirroring
RSPAN
ERSPAN |
|
IEEEE802.1d(STP)
IEEEE802.1w(RSTP)
IEEEE802.1s(MSTP)
Root Guard
BPDU Guard
BPDU Tunnel
ERPS(ITU-T G.8032) |
|
802.1Q, 4096 VLAN
MAC VLAN, VOICE VLAN, Private VLAN, Protocol VLAN, Multicast VLAN
QinQ, Selective QinQ, Flexible QinQ
GVRP
N:1 VLAN Translation
Broadcast / Multicast / Unicast Storm Control |
|
IGMP v1/v2/v3 Snooping and L2 Query
ND Snooping
MLDv1/v2 Snooping |
|
Port Security |
|
Flow control: HOL, IEEE802.3x
Bandwidth Control |
|
Fitur L3 |
Static Routing, RIPv1/v2, OSPFv2, BGP4
OSPFv3, BGP4+
OSPF Multiple Process
LPM Routing
Policy-based Routing (PBR) for IPv4 and IPv6
VRRP
URPF,
ECMP
BFD |
|
IGMP v1/v2/v3, IGMP Proxy,
DVMRP, PIM-DM, PIM-SM, PIM-SSM, any cast RP, MSDP
Static Multicast Route
Multicast Receive Control
Illegal Multicast Source Detection |
|
ARP Guard, Local ARP Proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit
Anti ARP Cheat, Anti ARP Scan |
|
DNS Client |
|
GRE Tunnel |
|
IPv6 |
6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE Tunnel
ICMPv6, ND, DNSv6
IPv6 LPM Routing, IPv6 Policy-Based Routing (PBR)
IPv6 VRRPv3, IPv6 URPF, IPv6 RA
RIPng, OSPFv3, BGP4+
MLD Snooping, IPv6 multicast VLAN
MLDv1/v2, PIM-SM/DM for IPv6, IPv6 Anycast RP, IPv6 ACL, IPv6 QOS |
|
MPLS |
MPLS, VRF, LDP |
|
MPLS L3 VPN, MPLS L2 VPN(VPLS), VPWS |
|
QoS |
8 Queues
SWRR, SP, WRR, DWRR, SDWRR, WRED
Traffic Classification Based on 802.1p CoS, ToS, DiffServ DSCP, ACL, port number
Traffic Shaping
PRI Mark/Remark |
|
ACL |
IP ACL, MAC ACL, IP-MAC ACL
Standard and Expanded ACL Based on source/destination IP or MAC, IP protocol, TCP/UDP
port, DSCP, ToS, IP Precedence), VLAN, Tag/Untag, CoS
REDIRECT and accounting-based ACL
Rules can be configured to port, VLAN
Time ranged ACL |
| Keamanan |
802.1x AAA
Port, MAC based authentication
Accounting based on time length and traffic
Guest VLAN and Auto VLAN |
|
RADIUS for IPv4 and IPv6 |
|
TACACS+ for IPv4 and IPv6 |
|
MAB |
|
DHCPv4/v6 |
DHCP Server/Client for IPv4/IPv6
DHCP Relay/Option 82
DHCP Snooping/Option 82 |
|
Layar Traffic |
sFlow Traffic Analysis |
|
Manajemen Jaringan |
CLI, WEB, Telnet, SNMPv1/v2c/v3 through IPv4 and IPv6
Syslog and external Syslog server
HTTP SSL
SNMP MIB, SNMP TRAP
FTP/TFTP
SNTP/NTP
RMOM 1,2,3,9
Authentication by radius
SSH v1/v2
Dual firmware images/ Configuration files
802.3ah OAM, 802.1ag OAM |
|
Fitur Data Center |
VXLAN
MLAG
Telemetry
Netconf
RoCE PFC & ECN
VSF (Virtual Switch Framework) |
