Model NumberTD500 Mesh V2: TD500V2-KGNN-S00, TD500 Mesh V2 White: TD500V2-WGNN-S00
Exterior ColorBlack, White
Materials - ExteriorSteel, Mesh, Plastic
Materials - Left Side PanelTempered Glass
Dimensions (L x W x H)499 x 210 x 500mm (incl. Protrusions), 430 x 210 x 477mm (excl. Protrusions)
Motherboard SupportMini-ITX, Micro-ATX, ATX, SSI-CEB, E-ATX* (*up to 12" x 10.7" motherboards, may impact cable management feature)
Expansion Slots7
3.5" Drive Bays2
2.5" Drive Bays3
I/O Panel - USB Ports2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 type C
I/O Panel - Audio In / Out1x Audio Jack
I/O Panel - Other1x ARGB Fan Hub
Pre-installed Fans - TopN/A
Pre-installed Fans - Front3x 120mm CF120 ARGB
Pre-installed Fans - RearN/A
Fan Support - Top3x 120mm, 2x 140mm
Fan Support - Front3x 120mm, 2x 140mm
Fan Support - Rear1x 120mm
Radiator Support - Top120 / 140 / 240 / 280 / 360mm (recommended maximum thickness - 55mm)
Radiator Support - Front120 / 140 / 240 / 280 / 360mm
Radiator Support - Rear120mm
Clearance - CPU Cooler165mm
Clearance - PSU200mm (Recommended up to 170mm)
Clearance - GFX410mm
Cable Routing - Behind Motherboard Tray19mm / 0.74"
Dust FiltersFront, Top, Bottom
Power Supply SupportBottom Mount, ATX
Warranty2 years
SizeMid Tower
SeriesMasterBox Series
Back Connector Motherboard SupportNo
