| Part No |
90NX09J1-M001F0 |
| Model Name |
B9406CAA-TH0041X |
| EAN Code |
4711636419314 |
| UPC Code |
199291419315 |
| WEEE |
0.603 |
| BASE UNIT |
VSNX09J1-BU1100 |
| |
|
| Operating System |
Windows 11 Pro |
| Office |
N/A |
| LCD cover-material |
Mg-Al |
| LCD cover-color |
Morn Grey |
| Top case-material |
Mg-Al |
| Top case-color |
Morn Grey |
| Bottom case-material |
Mg-Al |
| Bottom case-color |
Morn Grey |
| Military grade |
US MIL-STD 810H military-grade standard |
| Panel Size |
14.0-inch |
| OLED |
OLED |
| Brightness |
600nits |
| Resolution |
WQXGA+ (2880 x 1800) 16:10 |
| Glare |
Anti-glare display with Corning Gorilla® Glass |
| Color gamut |
DCI-P3: 100% |
| View angle(H/V) |
85/85 |
| Response time(Typ/Max) (ms) |
1/1 |
| Refresh rate |
120Hz |
| Contrast (Typ) |
1000000:1 |
| Touch Panel |
Touch screen |
| Screen-to-body ratio |
91 % |
| Pantone |
Pantone Validated |
| VESA CERTIFIED Display HDR |
VESA CERTIFIED Display HDR True Black 500 |
| Processor |
Intel® Core™ Ultra 7 Processor 356H 1.9 GHz (18MB Cache, up to 4.7 GHz, 16 Cores, 16 Threads); Intel® AI Boost NPU up to 50 TOPS |
| Neural processor |
Intel® AI Boost NPU |
| Chipset |
N/A |
| Discrete/Share |
Share |
| Integrated GPU |
Intel® Graphics |
| VRAM |
N/A |
| How to upgrade memory |
Not Available |
| Expansion Slot(includes used) |
1x M.2 2280 PCIe 4.0x4 |
| On board memory |
32GB LPDDR5X on board |
| Total System Memory |
LPDDR5X 32GB |
| Storage |
1TB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| Front-facing camera |
1080p FHD camera with IR function to support Windows Hello
With privacy shutter |
| On board Wireless |
Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 6.0 Wireless Card |
| NumberPad |
N/A |
| FingerPrint |
FingerPrint |
| Keyboard type |
Backlit Chiclet Keyboard |
| I/O ports |
2x USB 3.2 Gen 2 Type-A
2x Thunderbolt™ 4, compliant with USB4, support display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack |
| Audio |
Dolby Atmos
Built-in speaker
Built-in array microphone |
| Battery |
70WHrs, 2S2P, 4-cell Li-ion |
| AC Adapter |
TYPE-C, 90W AC Adapter, Output: 20V DC, 4.5A, 90W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord) |
| Required charging power |
Min: 80W
Max: 90W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
| Dimension (WxHxD) |
31.09 x 21.28 x 1.09 ~ 1.64 cm (12.24" x 8.38" x 0.43" ~ 0.65") |
| Weight (with Battery) |
1.10 kg (2.43 lbs) |
| Weight (w/o Battery) |
0.85 kg (1.87 lbs) |
| Security |
Fingerprint sensor
IR webcam with Windows Hello support
BIOS Protection Support
BIOS Self Recovery
CSME BIOS Redundancy Assistance
Intel CSME Firmware Resilience
Intel® BIOS Guard
Intel® Boot Guard
Microsoft Pluton Security Processor
Microsoft Secured-core PC
Microsoft Security Level 3
Platform Firmware Resiliency Support
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A |
| Antivirus |
N/A |
| MyASUS feature |
System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS |
| MyExpert Features |
Chat
Knowledge Hub
Advanced Tool
ExpertMeet(All)
File Search |
| Built-in Apps |
ASUS MyExpert (Not supported in China, 16GB RAM or higher)
AI ExpertMeet (China only)
MyASUS |
| Disclaimer for Built-in Apps |
Built-in Apps vary from OS SKU.
*MyASUS/McAfee don't support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
| Included in the Box |
Sleeve
USB3 TO LAN DONGLE |
| Reparability Index (for Belgium) |
09.1 |
| Reparability Index (for France) |
09.5 |
| Ecolabels & Compliances |
Energy star 9.0
FSC Mix
REACH
RoHS
TCO Certified |
| Base Warranty |
3Y Pick up/ return |
| Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty |
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgrade
ACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgrade
ACX14-017300NX//3Y HDD Retention*upgrade
ACX15-011800NX//3Y OnSite Service(Next Business Day); 3Y Accidental Damage Protection*; 3Y HDD_Retention*upgrade
*If you would like to know the details, please contact your sales teams. |
| Battery warranty |
Commercial NB Battery warranty follow system warranty.
* BP series Battery warranty 4Y-5Y by WEP option
* Chromebook series Battery warranty 2Y-5Y by WEP option
|
| Sustainable Material_Top cover(A part) |
90% PIR recycled aluminum |
| Sustainable Material_Panel frame (B part) |
30% PCR recycled plastic |
| Sustainable Material_Keyboard frame (C part) |
90% PIR recycled aluminum |
| Sustainable Material_Bottom cover (D part) |
90% PIR recycled aluminum |
| Sustainable Material_Battery |
30% PCR recycled plastic |
| Sustainable Material_Keyboard |
50% PCR recycled plastic cap |
| Sustainable Material_Speaker |
45% PCR + 5% OBP PCR recycled plastic enclosure |
