Output
Number of Ports
Total: 10
USB-A ×2
USB-C ×3
AC ×3
Car ×2
USB-C Output
5V?3A/ 9V?3A/ 15V?3A/ 20V?3A/ 20V?5A
(100W Max Per Port)
AC Output (Inverter Mode)
230V~ 10A Max, 50Hz, 2300W Max
AC Output (Bypass Mode)
220-240V~ 9.5A Max, 50Hz, 2280W Max
USB-A Output
5V?2.4A (2.4A Max Per Port)
Car Charger Output
12V?10A
Input
AC Input
220-240V~ 12A Max, 50Hz
AC Input Wattage (Charging)
2200W Max
AC Input Wattage (Bypass Mode)
2280W Max
XT60 Input
11-32V? 10A; 32V-60V? 20A (1000W Max)
