Classification
External access point
Frequency band
2,4 GHz i 5 GHz
Ports
2x 10/100/1000Base-T RJ45, 1 × 1000M SFP fiber port (combo)
PoE support
IEEE 802.3at (PoE+)
Dimensions (width x height x depth)
214mm × 214mm × 68mm
Operating Temperature
-40|65 ?
Relative humidity
10|90 %
Protection mode
IP68
Maximum power consumption
18 W
RF Management
Built-in antenna: 2.4GHz - 10dBi; 5GHz - 10dBi
Frequency Ranges
802.11a/n/ac: 5,150 GHz - 5,850 GHz; 802.11b/g/n/ax: 2,4 GHz - 2,483 GHz; 802.11ax: 5,150 GHz – 5,250 GHz, 5,250 GHz – 5,350 GHz, 5,725 GHz – 5,850 GHz
Modulations
802.11b: BPSK,QPSK,CCK; 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM; 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM; 802.11ax: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
Transmitting power
2,4GHz – 27 dBm; 5GHz –27 dBm
Power resolution adjustment
1 dBm
Virtual Access Point (BSSID)
32
Spatial Streams
1st module: 2,4 GHz – 2x2; 2nd module: 5 GHz – 2x2
WLAN - informations
Dynamic Channel Adjustment (DCA), Transmission Power Control (TPC), Blind Spot Detection and Reduction, Hidden SSID, RTS/CTS, RF Environment Scanning, Hybrid Access, Limit Access for Number of Users, Link Integrity Control, Limit Access to Weak Signal Terminals, Forced Roaming of Terminals with Weak Signals, Intelligent Client Switching according to Airtime Fairness, High Density Application Optimization
11n Extensions
40MHz Channel, 300 Mbps (PHY), Frame Aggregation (A-MPDU), Maximum Reliability Demodulation (MLD), Transmission Beam Forming (TxBF), Maximum Splicing Ratio (MRC), Spatial Time Coding (STBC), Low Density Parity Check Code (LDPC)
Security
Wireless, Source Address Validation (SAVI), Access control for various data packets - IPv4 and IPv6 and MAC addresses, Access control security for access points, based on MAC authentication, password authentication or authentication of digital certificates between the access point and the controller
Redirects
Static IP Address Configuration or Address Assignment by Dynamic DHCP, IPv6 Redirects, IPv6 Portal, Local Forwarding, Multicast Transmission, Roaming, Access Point Switching Terms, WDS
About QoS
WMM, Priority Mapping, QoS Policy Mapping, L2-L4 Packet Filtering and Flow Classification, Load Balancing, Bandwidth Limit, Call Acceptance Control (CAC), Power Saving Mode, Automatic AP Failover, Intelligent Terminal Identification, Multicast Conversion to Unicast Transmission
Management
Centralized management via controller; “fit” and “fat” modes, Remote and local maintenance, Local logs, Syslog and logs exported to a file, Alarm, Damage detection, Switching between “fit” and “fat” modes, Remote probe analysis, Dual-image (Dual-OS), Watchdog
