| General Specifications |
|
| |
|
|
|
100-240V – 50/60Hz
|
|
Power consumption in sleep mode
|
<2.0 Watts
|
|
Wireless network
|
802.11 a/b/g/n/ac (2.4GHz/5GHz)
|
|
2.4G Wi-Fi transmitter frequency range
|
2412 – 2472MHz (2.4GHzISM Band, USA 11 Channels, Europe and others 13 Channels)
|
|
2.4G Wi-Fi transmitter power
|
<20dBm
|
|
2.4G Wi-Fi modulation
|
DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
|
|
5G Wi-Fi transmitter power
|
<23dBm
|
|
5G Wi-Fi modulation
|
QPSK, BPSK, 16QAM, 64QAM, 256QAM
|
|
5G Wi-Fi transmitter frequency range
|
5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz
|
|
Note
|
CITATION 300 is intended to be used for streaming music. A consumer can stream Bluetooth audio to the speaker. A consumer can connect their speaker to the local Wi-Fi Network and stream music with Google Chromecast. In addition, the speaker will work with Google Home. This product is designed to be instantly on and ready to play music at a moment's notice, therefore, the Bluetooth and Wi-Fi connection must remain active at all times to ensure proper operation. CITATION 300 is in compliance with the European Union energy legislation. CITATION 300 will enter into sleep mode (networked standby) after 20 minutes without operation, after which it can be re-activated via Bluetooth or Wi-Fi.
|
| |
|
| |
|
| |
|
|
Audio Specifications
|
|
| |
|
|
Signal-to-noise ratio
|
>80dB
|
|
Supported audio formats
|
HE-AAC, LC-AAC, MP3, Vorbis, WAV (LPCM), FLAC, Opus
|
|
Output power
|
100W RMS
|
|
Transducer
|
2 x 20mm tweeter, 2 x 89mm woofer
|
| |
|
| |
|
| |
|
|
Dimensions
|
|
| |
|
|
Dimensions (W x H x D)
|
306 x 180 x 142 mm
|
|
Weight
|
4.1 kg (9lb)
|
| |
|
| |
|
| |
|
|
Control and Connection Specifications
|
|
| |
|
|
Bluetooth® version
|
4.2
|
|
Bluetooth transmitter frequency range
|
2402 – 2480MHz
|
|
Bluetooth transmitter power
|
<10dBm
|
|
Bluetooth transmitter modulation
|
GFSK,π/4 DQPSK, 8DPSK
|
