ZOTAC PC ZBOX, Intel Core i7 13700HX 5.4GHz, 2xHDMI, 2xDisplayport, 2xLAN, 5xUSB, 1xTB, Wifi, BT, RTX 3500 Ada

 Computing System

• Processor

  Intel Core i7-13700HX (16-core, up to 5.0 GHz)

• Chipset

  Intel, NVIDIA

• System Memory

  2 x DDR5-4800 SODIMM Slots (up to 64GB)

 Graphics

• Graphics Engine

  NVIDIA RTX 3500 Ada Generation Laptop GPU (12GB GDDR6 192-bit, 2250 MHz Boost Clock, 115W TDP

• Video Output

  2 x HDMI® Connector*
  2 x DisplayPort 1.4a (up to 7680x4320@60Hz)
  Up to Quad Display Support
  *Supports 4K 120Hz HDR, 8K 60Hz HDR, and Variable Refresh Rate as specified in the HDMI 2.1 Specification

 Storage

• Hard Drive

  N/A

• Mass Storage

  N/A

• Optical Drive

  N/A

• mSATA

  N/A

• M.2

  1 x M.2 NVMe PCIe 4.0 x4 SSD slot (2230,2242,2280,22110), 1 x M.2 NVMe PCIe 4.0 x4 / SATA SSD slot (2230, 2242,2280, 22110)

• Card Reader

  SDHC / SDXC (UHS-I / UHS-II)

 I/O Ports

• Audio

  Mic / Stereo Audio
  8-channel Digital via HDMI

• USB Port

  5 x USB 3.2

• LAN

  Dual 2.5Gbps Ethernet

• Antenna

  Dual Wi-FI SMA connetor

• Wifi

  Wi-Fi 6

• Bluetooth

  Bluetooth 5.2

• Legacy I/O

  N/A

• CIR Infrared Port

  N/A

• Thunderbolt

  Thunderbolt 4

• USB

  N/A

• IDE

  N/A

• VGA

  N/A

 Mechanical

• Kensington Lock

  Yes

• LED Indicators

  Power, HDD, WiFi

• Power Supply

  19V/300W AC-DC Power adapter

• Cooling system

  Fan + Heatsink

• ZBOX Dimensions

  209.8mm x 202.3mm x 67.5mm (8.26in x 7.96in x 2.65in)

• Case Mounting

  VESA & L-shaped mount

 Miscellaneous

• Supported OS

  Windows 11

• Accessories

  Universal AC adapter
  Power Cord (type dependent by region)
  L-Mount Kit + 6 x screws
  2 x Tri-band Antenna
  Quick Start Guide
