UBiQUiTi POE Adapter 2x1000Mbps, 48VDC @ 0.5A - POE-48-24W-G

Name: UBiQUiTi POE Adapter 2x1000Mbps, 48VDC @ 0.5A - POE-48-24W-G
Brand: UBIQUITI
SKU: CS_253379
Price: 10040 HUF
Availability: InStock

Cikkszám:

CS_253379

UBiQUiTi POE Adapter 2x1000Mbps, 48VDC @ 0.5A - POE-48-24W-G

Rendelhető

10 040 Ft

Részletek

POE48-24W-G
Dimensions	92 x 60 x 33 mm (3.62 x 2.36 x 1.30")
Weight	158.5 g (5.59 oz)
Output Voltage	48VDC @ 0.5A
LAN Activity Indicator	No
Gigabit LAN Port	Yes
Remote Reset Capability	No
Reset Button	No
Rated Voltage	100-240VAC @ 50/60Hz
Input Current	0.6A @ 120VAC, 0.4A @ 240VAC
Inrush Current	<65A Peak @ 120VAC, <130A Peak @ 230VAC
Efficiency	80+%
Output Ripple	1% Max.
Switching Frequency	65 kHz
Line Regulation	≤ 3%
Load Regulation	≤ 5%
2-Pair Powering	Pins 4, 5 (+) and Pins 7, 8 (-)
4-Pair Powering	–
Operating Temperature	0 to 40° C (32 to 104° F)
Storage Temperature	-30 to 70°C (-22 to 158° F)
Operating Humidity	35 to 95% Noncondensing
AC Connector	IEC-320 C6
Data IN / POE	RJ45 Shielded Socket
Surge Protection	Difference and Common Mode
Clamping Protection	11V Data, 60V Power
Max. Surge Discharge	1500A (8/20 μs) Power
Peak Pulse Current	36A (10/1000 μs) Data
Shunt Capacitance	<5 pF data
Response Time	<1 ns
Certifications	CE, FCC, IC, UL

Adatok

Gyártó:

UBIQUITI

Gyártói cikkszám:

POE-48-24W-G

EAN:

810354023088

EAN:

810354023088

Garancia:

12 hónap

Gyártó:

UBIQUITI

Portok száma:

Tömeg:

160 g/db
