Connector(s)
Connector A
1 - HDMI (19 pin)
Connector B
1 - HDMI (19 pin)
Environmental
Operating Temperature
0º - 26ºC (32º - 79ºF)
Storage Temperature
0º - 35ºC (32º - 90ºF)
Humidity
5 - 75% (non-condensing)
Hardware
Connector Plating
Gold
Cable Jacket Material
PVC - Polyvinyl Chloride
Cable Shield Material
Aluminum-Mylar Foil with Braid
Fire Rating
CL2 Rated
Chipset ID
Spectra7 - HT8181
Packaging Information
Shipping (Package) Weight
1.5 kg [3.2 lb]
Package Quantity
1
Package Length
30.5 cm [12.0 in]
Package Width
27.8 cm [10.9 in]
Package Height
51 mm [2.0 in]
Performance
Maximum Digital Resolutions
3840 x 2160 (Ultra HD 4K) @ 60hz
Audio Specifications
Physical Characteristics
Weight of Product
1.5 g [0.1 oz]
Color
Black
Connector Style
Straight
Wire Gauge
24 AWG
Cable Length
15 m [49.2 ft]
Product Length
15 m [49.2 ft]
Product Width
2.2 cm [0.9 in]
Product Height
1.1 cm [0.4 in]
Special Notes / Requirements
Note
This cable features unidirectional architecture which requires that the cable is installed in the correct direction. Please ensure that the HDMI connector labelled with "TV" is connected to the display, in order to ensure that the device and the HDMI source are connected properly.
What's in the Box
Included in Package
1 - HDMI cable
