| Management Type |
Web Managed |
| CPU |
Intel® Celeron® J4115 quad-core 1.8 GHz processor (burst up to 2.5 GHz) |
| CPU Architecture |
64-bit x86 |
| System Memory |
4 GB (1 x 4 GB) |
| Drive Bays |
2 x 2.5-inch SATA 6Gb/s, 3Gb/s |
| Number of Ports |
16 |
| 1GbE (RJ45) |
14 |
| 1GbE SFP/RJ45 Combo Ports |
2 |
| Total PoE Ports |
16 |
| PoE PSE (802.3af, 15.4W) |
Ports 1-16 |
| PoE+ PSE (802.3at, 30W) |
Ports 1-16 |
| PoE++ PSE (802.3bt, 60W) |
Ports 1-4 |
| PoE Power Output |
Ports 1-4 (60W), Ports 5-16 (30W) |
| Total PoE Power Budget |
360W |
| PCIe Slot |
Slot 1: PCIe Gen2 (x2)
Slot 2: PCIe Gen2 (x2) |
| USB 3.2 Gen 1 port |
1 |
| USB 2.0 port |
2 |
| Management Port |
1 x 1GbE |
| USB 3.2 Gen 2 (10Gbps) Port |
Optional via PCIe adapter |
| HDMI Output |
1 |
| Power Supply Description |
Internal Power Supply Unit |
| Max. Power Consumption |
418W |
| Input Power Type |
AC |
| Input Voltage Range |
100-240VAC, 50/60 Hz |
| MAC Address Table |
8K |
| Total Non-Blocking Throughput |
16Gbps |
| Switching Capacity |
32Gbps |
| Management Interface |
Web |
| Energy Efficient Ethernet (IEEE 802.3az complaint) |
Yes |
| Fan |
System: 2 x 4 cm (12V DC) |
| Supported Standards |
IEEE 802.3u 100Tx Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3z 1000Base-X
IEEE 802.3x Full-duplex flow control
IEEE 802.3af/at/bt Power-over-Ethernet (PoE)
IEEE 802.1q Virtual LANs (VLAN)
IEEE 802.1p QoS Protocol for Traffic Prioritization |
| Form Factor |
Rackmount |
| LED Indicators |
Per Port: Link/Activity/Speed/PoE
Per System: Warning/PoE/Fan |
| LCD Management |
Yes |
| Buttons |
Device PSU power button
Host power button
Host reset button(load default)
Switch reset button |
| Dimensions (HxWxD) |
47,2 × 436,2 × 326,2 mm |
| Weight (Net) |
4.41 kg |
| Weight (Gross) |
5.56 kg |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Relative Humidity |
5% to 95% non-condensing, wet bulb: 27°C (80.6°F) |
| Certifications |
CE, FCC, VCCI, BSMI RCM, CCC |
| Electromagnetic Compliance |
CLASS A, UL62368 |
| Jumbo Frames |
9k |
| QTS Built-in |
Yes |
| Internal Network Bandwidth |
2 x 1GbE |
| Graphics Processors |
Intel® HD Graphics 600 |
| Floating Point Unit |
Yes |
| Encryption Engine |
(AES-NI) |
| Maximum Memory |
8 GB |
| Memory Slot |
2 x SODIMM DDR4 |
| Flash Memory |
4GB (Dual boot OS protection) |
| Drive Compatibility |
2.5-inch bays:
2.5-inch solid-state drives
2.5-inch hard disk drives |
| Hot-swappable |
Yes |
| M.2 SSD Slots |
Optional via PCIe adapter |
| SSD Cache Acceleration Support |
Yes |
| File System: Internal Hard Drive |
EXT4 |
| File System: External Hard Drive |
EXT3, EXT4, NTFS, FAT32, HFS+, exFAT (optional license) |
