| Management Type |
Unmanaged |
| Number of Ports |
11 |
| 10GbE SFP+ |
3
10G only
Note: Compatibility issues with the Intel X520 ethernet network adapter might cause the ports to randomly switch between port up and port down status.
|
| 1GbE (RJ45) |
8 |
| Power Supply Description |
Adapter |
| Max. Power Consumption |
36W |
| Input Power Type |
AC |
| Input Voltage Range |
100-240VAC, 50/60 Hz |
| MAC Address Table |
16K |
| Total Non-Blocking Throughput |
38Gbps |
| Switching Capacity |
76Gbps |
| Fan |
Fanless |
| Fanless |
Yes |
| Supported Standards |
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-TX
IEEE 802.3ab 1000BASE-T
IEEE 802.3an 10GBASE-T |
| Form Factor |
Desktop |
| LED Indicators |
Per Port: Speed/Link/Activity
Per System: Power/Status |
| Dimensions (HxWxD) |
42.5 × 290 × 127 mm |
| Weight (Net) |
0.74 kg |
| Weight (Gross) |
1.16 kg |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Relative Humidity |
5~95% Non-condensing |
| Certifications |
CE, FCC, VCCI, BSMI RCM, CCC |
| Electromagnetic Compliance |
CLASS B, UL62368 |
| Jumbo Frames |
10k |
| Warranty |
2 Years |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications.
Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Product images are for illustrative purposes only and may differ from the actual product. Due to differences in monitors, colors of products may also appear different to those shown on the site.
Designs and specifications are subject to change without notice.
