| CPU |
Intel® Core™ i3-8100T 4-core 3.1 GHz Processor |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Intel® UHD Graphics 630 |
| Floating Point Unit |
Yes |
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
Yes |
| System Memory |
8 GB SODIMM DDR4 (2 x 4 GB) |
| Maximum Memory |
32 GB ( 2 x 16 GB) |
| Memory Slot |
2 x SO-DIMM DDR4 |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
6 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
| Hot-swappable |
Yes |
| M.2 SSD Slot |
2 x M.2 2280 PCIe Gen3 x2 slots |
| SSD Cache Acceleration Support |
Yes |
| Gigabit Ethernet Port (RJ45) |
2 |
| 10 Gigabit Ethernet Port |
1 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| Wake on LAN (WOL) |
Yes |
| Jumbo Frame |
Yes |
| Thunderbolt Port |
2 (Thunderbolt™ 3) |
| PCIe Slot |
2
Slot 1: PCIe Gen 3 x16 (CPU)
Slot 2: PCIe Gen 3 x4 (PCH)
Slot 1 is preinstalled with a Thunderbolt 3 adapter
|
| USB 3.2 Gen 1 port |
1 |
| USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-C USB 3.2 Gen 2 5V/3A 10Gbps
2 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
| IR Sensor |
(QNAP RM-IR004 & MCE) |
| HDMI Output |
1, HDMI 2.0 (up to 3840 x 2160 @ 60Hz) |
| Audio Input |
- (No longer available on units manufactured on or after 2021/1/1) |
| Audio Output |
- (The line out jack and speaker are no longer available on units manufactured on or after 2021/1/1) |
| Form Factor |
Tower |
| LED Indicators |
HDD 1-6, Status, LAN, USB port, M.2 port |
| LCD Display/ Button |
Yes |
| Buttons |
Power, Reset, USB Copy |
| Dimensions (HxWxD) |
188.2 × 264.3 × 279.6 mm |
| Weight (Net) |
6.553 kg |
| Weight (Gross) |
8.07 kg |
| Operating temperature |
0 - 40 °C (32°F - 104°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27°C (80.6°F) |
| Power Supply Unit |
250W, 100-240V |
| Power Consumption: HDD Sleep Mode |
26.52 W |
| Power Consumption: Operating Mode, Typical |
45.6 W
Tested fully populated with WD10EFRX hard drives.
|
| Fan |
System fan: 2 x 92mm, 12VDC
CPU fan: 2 x 60mm blower fan |
| Sound Level |
23.8 db(A) |
| System Warning |
Voice prompts or Buzzer |
| Kensington Security Slot |
Yes |
| Max. Number of Concurrent Connections (CIFS) |
700 |
