Panel Size |
|
Active Display Area (mm) |
|
Curvature |
|
Panel Type |
Rapid IPS with Mini-LED (1152 Zones) |
Panel Resolution |
Normal: 3840 x 2160 (UHD) |
|
Dual Mode: 1920 x 1080 (FHD) |
Pixel Pitch (H x V) |
0.15525 (H) x 0.15525 (V) |
Aspect Ratio |
|
Brightness (nits) |
|
|
HDR: 1000 cd/m2 (Peak) |
Contrast Ratio |
|
DCR |
|
Signal Frequency |
Normal: 180~356KHz (H) / 48~160Hz (V) |
|
Dual Mode: 180~356KHz (H) / 48~320Hz (V) |
ACTIVATED RANGE |
|
|
Dual Mode: 48~320Hz |
Refresh Rate |
|
|
Dual Mode: 320Hz |
Response time |
|
DYNAMIC REFRESH RATE TECHNOLOGY |
|
HDR Support |
|
Video ports |
1x DisplayPort 1.4a (HBR3) |
|
2x HDMI™ 2.1 (UHD@160Hz) |
|
1x Type-C (DP alt.) w/ 15W Power Delivery |
Audio ports |
|
Viewing Angle |
|
Adobe RGB / DCI-P3 / sRGB |
100% / 98% / 143% (CIE1976 Standard) |
Surface Treatment |
|
Display Colors |
1.07B, 10 bits (8 bits + FRC) |
Console Mode |
Supported Resolution & Refresh Rate: |
|
1080p: 60Hz and 120Hz |
|
1440p: 60Hz and 120Hz |
|
2160p: 60Hz and 120Hz |
|
HDMI™ CEC: Supported |
|
VRR: PS5 and Xbox Supported |
Frameless Design |
|
PIP / PBP Function |
|
Power Type |
External Adaptor 19V 7.89A |
Power Input |
|
Adjustment (Tilt) |
|
Adjustment (Swivel) |
|
Adjustment (Pivot) |
|
Adjustment (Height) |
|
Kensington Lock |
|
VESA Mounting |
|
Dimension with Stand (W x D x H) |
613.10 x 227.90 x 423.53 mm |
Dimension without Stand (W x D x H) |
613.10 x 68.77 x 375.31 mm |
Weight (NW / GW) |
7.5 kg (16.54 lbs) / 11 kg (24.25 lbs) |
Carton Dimension (W X D X H) |
|
Accessories |
1x DP Cable (1.4a), 1x Power Cord (C5), 1x AC Adaptor, 1x Quick Guide, 4x VESA Wall Mount Screw |
Note |
HDMI™: Normal (UHD): 3840 x 2160 (Up to 160Hz) |
|
Dual Mode (FHD): 1920 x 1080 (Up to 320Hz) |
|
DisplayPort: Normal (UHD): 3840 x 2160 (Up to 160Hz) |
|
Dual Mode (FHD): 1920 x 1080 (Up to 320Hz) |
|
Type-C: Normal (UHD): 3840 x 2160 (Up to 160Hz) |
|
Dual Mode (FHD): 1920 x 1080 (Up to 320Hz) |
|
Support: HDMI™ CEC, PIP/PBP; Non Support: KVM |
