Specifications
| Details |
| Product code |
CRS518-16XS-2XQ-RM |
| Architecture |
MIPSBE |
| CPU |
QCA9531 |
| CPU core count |
1 |
| CPU nominal frequency |
650 MHz |
| RouterOS license |
6 |
| Operating System |
RouterOS |
| Size of RAM |
64 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-40°C to 70°C |
| Suggested price |
$1595.00 |
Powering
| Details |
| Number of AC inputs |
2 |
| AC input range |
100-240 |
| Frequency (Hz) |
47-63 |
| Max power consumption |
77 W |
| Max power consumption without attachments |
45 W |
| Cooling type |
4 fans |
Ethernet
| Details |
| 10/100 Ethernet ports |
1 |
Fiber
| Details |
| Number of 25G SFP28 ports |
16 |
| Number of 100G QSFP28 ports |
2 |
Peripherals
| Details |
| Serial console port |
RJ45 |
| Number of USB ports |
1 |
| USB slot type |
USB type A |
| Max USB current (A) |
1 |
Other
| Details |
| CPU temperature monitor |
Yes |
| PCB temperature monitor |
Yes |
| Voltage Monitor |
Yes |
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
20 |
Included parts
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
