Connectivity
10/100/1000 Base-T (RJ45) ports
8
100/1000 Base-X (SFP) ports
2
Performance
Switching matrix
20 Gbps
Data transfer rate
14,88 Mpps
Packet Buffer
0,5 MB
JUMBO Frame
10 K
MAC address table
8 k
Multi-broadcast support
500
MAC address table additional information
Shared MAC address array for unicast and multicast (1:1 ratio)
ACL Table
1,4 K
Number of Vlan Interfaces (IP)
16
CPU Clock
500 MHz
Number of Base-T ports (RJ45)
8
Available Base-T (RJ45) port speeds
10 ; 100 ; 1000
Number of Base-X ports (Optical)
2
Available Base-X (Optical) port speeds
100 ; 1000
Console port- RS-232 (RJ45)
Yes
OOB Management Port
No
Port USB
No
PoE available
Yes
Number of PoE/PoE+ ports available
8
PoE power budget
70 W
Functionality of VSF
No
Functionality of PIM Router
No
Power supply
1 x 230V
RPSU
No
Hot Swap PSU
No
RPS
No
Cooling
Active
Flash memory
16 MB
RAM memory
128 MB
Features
Enhanced Accessibility Features
IEEE 802.1D STP/802.1w RSTP/802.1s MSTP, IEEE 802.3ad LACP, Virtual Cable Testing, DDM, LLDP / LLDP-MED, Loop guard, ERPS (ITU-T G.8032)
Traffic control
802.1Q VLAN, Port-Based VLAN, Protocol-Based VLAN, IP Subnet-based VLAN, Voice VLAN, Mac VLAN, Source/Destination IP LACP Algorithm (Load Balancing), GVRP, 802.1ad Vlan Stacking (QinQ), Selective QinQ, Flexible Source/Destination QinQCP IP (Load Balancing), GVRP, IEEE 802.1ad Vlan Stacking (QinQ), Selective QinQ, Flexible QinQ
Security
Layer 2 MAC filtering, BPDU Tunnel, Login authentication and authorization by RADIUS and TACACS+, TACACS+ accounting/ auditing, SSH v1/v2, DHCP/DHCPv6 snooping, IP/IPv6 Source Guard, Port security, IEEE 802.1x port-based / mac-based
QoS
802.1p Priority Queues per Port, 802.1p Queuing method, Trusted COS/TOS/IP Precedence/DSCP/Port number, Broadcast Storm Control, Rate Limiting, port based, Strict priority, Weighted Round Robin, Weighted Deficit Round Robin, Strict priority in Weighted Round Robin
Multiemisja L2/L3
Multicast VLAN, IGMP v1, v2, v3, IGMP Query, IGMP Snooping (v1,v2,v3), IGMP Snooping Fast Leave (v2,v3), IPv6 MLD v1/v2 Snooping
L3 IPv6
IPv4/IPv6 protocol dual stack, IPv6 address
Management
RS-232 (RJ45) console port, GUI (Web), Telnet, SNMP v1/v2c/v3, TFTP/FTP, configuration backup and restore, multi-level CLI, DHCP Client/Relay/Server, DHCP relay to VLAN, DHCP 43 /60/82 option, DHCPv6 37/38 option, DHCPv6 relay/server, SNTP/NTP, sFlow, port mirroring over IP/TCP/UDP, RSPAN, IEEE 802.3ah EFM
MIB
RFC1066 — based on TCP/IP MIB
RFC1213, 1157 — SNMPv2C/v3 MIB
RFC1493 — MIB Bridge
RFC 2674 - MIB Extension Bridge
RFC1643 — Ethernet MIB
RFC1757 — RMON Group 1,2,3,9
RFC2925 — Remote MIB Management
RFC2233 — SMiV2 MIB
