PFCActive PFC
ErP 2014 Lot 3Yes
Input Frequency50-60Hz
ATX 24 Pin Connectors1
EPS 4+4 Pin Connectors1
EPS 8 Pin Connector1
Fan Size120mm
Power Good Signal100 - 500 ms
MTBF>100,000 Hours
Category500 to 750W
ModularNon Modular
Fan BearingHDB
Efficiency85% Typically
80 Plus EfficiencyWhite
PCI-e 6+2 Pin Connectors4
80 PLUS Rating80 PLUS Standard 230V EU
Operating Temperature40°C
SATA Connectors6
Peripheral 4 Pin Connectors3
ProtectionsOVP
ATX VersionATX 12V V2.52
Input Current5A
SeriesMWE White Series
ProtectionsOPP
ProtectionsSCP
Dimensions (L x W x H)140 x 150 x 86 mm
Hold Up Time>14ms at 100% Full Load@230Vac
ProtectionsUVP
ProtectionsOTP
Fan Speed2400 RPM
RegulatoryCCC
Input Voltage200-240Vac
RegulatoryCE
RegulatoryTUV-RH
Noise Level @ 20%13.8 dBA
RegulatoryRCM
RegulatoryEAC
Noise Level @ 100%35.5 dBA
RegulatorycTUVus
RegulatoryFCC
Noise Level @ 50%22.1 dBA
RegulatoryBSMI
RegulatoryKC
RegulatoryCB
ModelMPE-6001-ACABW
