| Model Number |
MCC-C700M-MG5N-S00, MCC-C700M-WG5N-S00 |
|
| Color(s) |
Grey, Silver & Black (MCC-C700M-MG5N-S00), Silver & White (MCC-C700M-WG5N-S00) |
|
|
|
| Materials - Side Panel |
Curved Tempered Glass, Steel |
|
| Dimensions (L x W x H) |
650 x 306 x 651mm / 25.6 x 12.0 x 25.6 inch |
|
| Motherboard Support |
Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12” x 10.7” motherboards) |
|
|
|
|
|
| 2.5" / 3.5" Drive Bays (Combo) |
4+1 (In The Accessory Box) |
|
|
|
| I/O Port - USB Ports / USB 3.1 Type-C |
1 |
|
| I/O Port - USB Ports / USB 3.0 Type-A |
4 |
|
| I/O Port - Audio - 3.5mm Headset Jack (Audio+Mic) |
1 |
|
| I/O Port - Audio - 3.5mm Mic Jack |
1 |
|
| I/O Port - Fans / Lighting |
Fan Speed Control Button, ARGB Control Button |
|
| Pre-installed Fans - Front |
3x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin) |
|
| Pre-installed Fans - Rear |
1x 140mm PWM Fan (Speed: 1200RPM / Connector: 4Pin) |
|
| Fan Support - Top |
3x 120/140mm |
|
| Fan Support - Front |
3x 120/140mm |
|
| Fan Support - Rear |
1x 120/140mm |
|
| Fan Support - Bottom |
2x 120/140mm (Bracket Needed) |
|
| Radiator Support - Top |
120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD, maximum thickness clearance 70mm) |
|
| Radiator Support - Front |
120mm, 140mm, 240mm, 280mm, 360mm, 420mm (remove ODD) |
|
| Radiator Support - Rear |
120mm, 140mm |
|
| Radiator Support - Bottom |
120mm, 140mm, 240mm |
|
| Clearance - CPU Cooler |
198mm |
|
| Clearance - GFX |
490mm (w/o 3.5" HDD BRK), 320mm (w/ 3.5" HDD BRK) |
|
| Accessories |
Riser Cable PCIe 4.0 x16 - 400mm (Compatible with PCI Express 4.0 Gen 3 and below) |
|
|
|
|
|
