| Product Number |
MLY-D24M-A23PZ-R1 |
|
|
|
| CPU Socket |
LGA1700, LGA1200, LGA2066, LGA2011-v3, LGA2011, LGA1151, LGA1150, LGA1155, LGA1156, AM5, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1, TR4 |
|
| Radiator Material |
Aluminum |
|
| Radiator Dimensions |
277 x 119.6 x 27.2 mm / 10.7 x 4.7 x 1.07 inch |
|
| Pump Dimensions |
89 x 75 x 40 mm / 3.5 x 2.95 x 1.57 inch |
|
|
|
| Pump Noise Level |
15 dBA (Max) |
|
|
|
| Pump Rated Voltage |
12 VDC |
|
| Pump Power Consumption |
6W |
|
| Fan Dimensions (L x W x H) |
120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch |
|
|
|
| Fan LED Type |
Addressable Gen 2 RGB |
|
| Fan Speed |
0-2300 RPM ± 10% |
|
| Fan Airflow |
72.37 CFM (Max) |
|
| Fan Noise Level |
32 dBA (Max) |
|
| Fan Pressure |
2.96 mmH2O (Max) |
|
| Fan Bearing Type |
Oli Reflow Bearing System (ORBS) |
|
| Fan Life Expectancy |
>160,000 Hours |
|
| Fan Power Connector |
4-Pin (PWM) |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Cooler Type |
Liquid Cooler |
|
|
|
| Patent Number |
US10739084B2, US11061450B2, US10409341B2, US11320874B2, US11474574B2 |
|
