Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity
8
Installed SFP+ modules quantity
8
MAC address table
16000 entries
Switching capacity
320 Gbit/s
Networking standards
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3an,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Design
Product colour
Black, Grey
Certification
UL (UL 60950), CSA (CSA 22.2), FCC 15 (CFR 47) A
Management features
Quality of Service (QoS) support
Y
Configuring Location Settings (CLI)
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
10G Ethernet (100/1000/10000)
10G Ethernet (copper) ports quantity
8
Installed SFP+ modules quantity
8
Power over Ethernet (PoE)
Power over Ethernet (PoE)
N
Data transmission
MAC address table
16000 entries
Switching capacity
320 Gbit/s
Forwarding rate
238.08 Mpps
Number of static routes
990
Number of IP interfaces
128
Packet buffer memory
3 MB
Protocols
Management protocols
SNMP v1/2c/3, Telnet, HTTP/HTTPS, SSH, RADIUS, BOOTP, SNTP
GARP VLAN Registration Protocol (GVRP)
Y
Network
Networking standards
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3an,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Copper ethernet cabling technology
10BASE-T,10GBASE-T,100BASE-TX,1000BASE-T
Cable types supported
Cat5e
Broadcast storm control
Y
Head-of-line (HOL) blocking
Y
Ethernet LAN data rates
10,100,1000,10000 Mbit/s
Virtual LAN features
IP subnet?based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, VLAN mapping, Voice VLAN
VLAN mapping type
1:1 VLAN mapping
Power
Redundant power supply (RPS) support
N
Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Performance
Physical stacking (units)
4
Processor frequency
800 MHz
Mean time between failures (MTBF)
798504 h
Multicast features
Multicast Listener Discovery (MLD) snooping
MLD v1/2
Security
DHCP features
DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 relay
Access Control List (ACL)
Y
Access Control List (ACL) rules
1024
Security algorithms
802.1x RADIUS,SSH,SSH-2,SSL/TLS
BPDU filtering/protection
Y
Authentication
Guest VLAN, Port-based authentication
Authentication type
IEEE 802.1x,RADIUS
Packaging data
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-25 - 70 °C
Operating relative humidity (H-H)
10 - 90 %
Storage relative humidity (H-H)
10 - 90 %
Heat dissipation
196.88 BTU/h
Weight & dimensions
Technical details
Sustainability compliance
Y
Sustainability certificates
CE
