CHIEFTEC Tápegység A-90 750W 80+ Gold moduláris BOX

Cikkszám:
CS_336062
CHIEFTEC Tápegység A-90 750W 80+ Gold moduláris BOX
Rendelhető
61 290 Ft
Részletek
Model A90 750W
Article no. GDP-750C
EAN code 4710713230842
Weight (Net/Gross) 2.29kg / 2.6kg
AC Input 200-240V / 5.0A
Frequency 47 - 63Hz
+5V 22A
+3,3V 22A
+5V & +3,3V combined 120W
+12V1 62A
+12V2 -
+12V1, +12V2 combined 744W
P.F. >0,9
-12V 0,3A / 3,6W
+5VSB 2,5A / 12,5W
Maximum Power 750W

Connectors
20+4 PIN ATX 1
8 PIN EPS(4+4) 1
8 PIN PCIe (6+2) 4
SATA 8
MOLEX/FLOPPY 3/1

Cable length (mm)
20+4 PIN ATX 550
8 PIN EPS(4+4) 550
8 PIN PCIe (6+2) 2X 550/150
SATA 2x 550/150/150/150
MOLEX/FLOPPY 550/150/150/150

Features
ATX12V Version ATX 12V 2.3
Efficiency >90%
Dimension (DxWxH) 160mm x 150mm x 87mm
PFC Active PFC (0,9)
Fan 140mm silent fan
Security AFC (Automatic Fan speed Control)
OCP (Over Current Protection)
OPP (Over Power Protection)
OTP (Over Temperature Protection)
OVP (Over Voltage Protection)
SCP (Short Circuit Protection)
SIP (Surge & Inrush Protection)
UVP (Under Voltage Protection)
Warranty 24 Months
Adatok
Gyártó:
CHIEFTEC
Gyártói cikkszám:
GDP-750C
EAN:
4710713230842
EAN:
4710713230842
Garancia:
24 hónap
Gyártó:
CHIEFTEC
Hűtés típusa:
Low Noise (12cm)
Teljesítmény:
750
Tömeg:
2,331 kg/db
