Dimensions
120 (L) x 120 (W) x 38 (H) mm
Weight
328 g
Flammability UL 94
V-0
Operating Ambient Temperature
-10°C~70°C
Fan Specifications
Speed
800–8000 rpm, PWM controlled
Static Pressure
37 mmH2O
Airflow
220 cfm | 370 m³/h
Bearing
Dual Ball Bearing with Brass Housing
Cable Length
300 mm, Black
Connector
2510 4-Pin Fan Connector
Current | Voltage
2.2 A | 12.0 V DC
Start-Up Voltage
6.5 V DC
Current (Maximum)
3.2 A
Motor Protection Features
Reverse Polarity Protection, Over Voltage Protection, Over Current Protection
