Operating Ambient Temperature
0–40 °C
Dimensions
92 (L) x 92 (W) x 25 (H) mm
Net Weight
106 g
Fan Specifications
Fan Speed
200–3000 rpm (PWM controlled),
0 rpm below 5 % PWM
Airflow
38.83 cfm | 65.97 m³/h
Static Pressure
3.12 mmH2O
Fan Bearing
Fluid Dynamic Bearing
Typical Voltage
12 V DC
Start Up Voltage
5 V DC
Current
0.12 A
Cable Length
400 mm + 80 mm Daisy-Chain Cable
Connector
4-Pin Fan Plug + 4-Pin Socket
